回转窑衬里用标准砖型尺寸

砖号适用窑内径（m）尺寸尺寸（mm）容积LHABABHLD国际磷酸盐系列VDZ系列（国际通用系列，中部宽度恒定为71.5mm，但带*者例外）P111.1-1.51981007160B21878.065.01801982,1602.55P161.6-1.91981208069B31876.566.51801982,7542.55P202.0-2.41981508170B41875.068.01801983,8572.55P252.5-2.91981509080B61874.069.01801985,3282.55P303.0-3.21981809281B718*78.074.01801987,0202.71P333.3-3.51981808374B22078.065.02001982,4002.83P363.6-3.919818010090B32076.566.52001983,0602.83P404.0-4.21982009081B42075.068.02001984,2862.83P434.3-4.51982009788B62074.069.02001985,9202.83P464.6-4.91982009284B820*78.074.02001987,8003.01PC1-11.1-1.51981009079B22278.065.02201982,6403.11PC1-21.1-1.51981006049B32276.566.52201983,3663.11PC1-31.1-1.51981005039B42275.068.02201984,7143.11PC1-41.6-1.91981209079B62274.069.02201986,5123.11PC1-51.6-1.91981206049B822*78.074.02201988,5803.31PC1-61.6-1.91981205039ISO系列（国际通用系列，大头宽度恒定为103mm）PC2-12.0-2.919815010090216103.086.01601981,9392.99PC2-22.0-2.91981507060316103.092.01601982,9963.09PC2-32.0-2.91981506050218103.084.01801981,9523.33PC3-13.0-3.9198180110101318103.090.51801982,9663.45PC3-23.0-3.91981807061418103.093.51801983,9033.50PC3-33.0-3.91981806051618103.097.01801986,1803.56PC4-14.0-4.919820010091220103.082.02001981,9623.66PC4-24.0-4.91982007061320103.089.02001982,9433.80PC4-34.0-4.91982006051420103.092.52001983,9243.87 520103.094.72001984,9643.91620103.096.22001986,0593.94820103.097.82001987,9233.98222103.080.32201981,9963.99322103.088.02201983,0214.16422103.091.52201983,9414.24622103.095.52201986,0434.32822103.097.32201987,9514.36425103.090.02501983,9624.78625103.094.52501986,0594.89

在线咨询

产品详情

砖号	适用窑内径（m）	尺寸					尺寸（mm）					容积
砖号	适用窑内径（m）	L	H	A	B		A	B	H	L	D	容积
国际磷酸盐系列						VDZ系列（国际通用系列，中部宽度恒定为71.5mm，但带*者例外）
P11	1.1-1.5	198	100	71	60	B218	78.0	65.0	180	198	2,160	2.55
P16	1.6-1.9	198	120	80	69	B318	76.5	66.5	180	198	2,754	2.55
P20	2.0-2.4	198	150	81	70	B418	75.0	68.0	180	198	3,857	2.55
P25	2.5-2.9	198	150	90	80	B618	74.0	69.0	180	198	5,328	2.55
P30	3.0-3.2	198	180	92	81	B718*	78.0	74.0	180	198	7,020	2.71
P33	3.3-3.5	198	180	83	74	B220	78.0	65.0	200	198	2,400	2.83
P36	3.6-3.9	198	180	100	90	B320	76.5	66.5	200	198	3,060	2.83
P40	4.0-4.2	198	200	90	81	B420	75.0	68.0	200	198	4,286	2.83
P43	4.3-4.5	198	200	97	88	B620	74.0	69.0	200	198	5,920	2.83
P46	4.6-4.9	198	200	92	84	B820*	78.0	74.0	200	198	7,800	3.01
PC1-1	1.1-1.5	198	100	90	79	B222	78.0	65.0	220	198	2,640	3.11
PC1-2	1.1-1.5	198	100	60	49	B322	76.5	66.5	220	198	3,366	3.11
PC1-3	1.1-1.5	198	100	50	39	B422	75.0	68.0	220	198	4,714	3.11
PC1-4	1.6-1.9	198	120	90	79	B622	74.0	69.0	220	198	6,512	3.11
PC1-5	1.6-1.9	198	120	60	49	B822*	78.0	74.0	220	198	8,580	3.31
PC1-6	1.6-1.9	198	120	50	39	ISO系列（国际通用系列，大头宽度恒定为103mm）
PC2-1	2.0-2.9	198	150	100	90	216	103.0	86.0	160	198	1,939	2.99
PC2-2	2.0-2.9	198	150	70	60	316	103.0	92.0	160	198	2,996	3.09
PC2-3	2.0-2.9	198	150	60	50	218	103.0	84.0	180	198	1,952	3.33
PC3-1	3.0-3.9	198	180	110	101	318	103.0	90.5	180	198	2,966	3.45
PC3-2	3.0-3.9	198	180	70	61	418	103.0	93.5	180	198	3,903	3.50
PC3-3	3.0-3.9	198	180	60	51	618	103.0	97.0	180	198	6,180	3.56
PC4-1	4.0-4.9	198	200	100	91	220	103.0	82.0	200	198	1,962	3.66
PC4-2	4.0-4.9	198	200	70	61	320	103.0	89.0	200	198	2,943	3.80
PC4-3	4.0-4.9	198	200	60	51	420	103.0	92.5	200	198	3,924	3.87
						520	103.0	94.7	200	198	4,964	3.91
						620	103.0	96.2	200	198	6,059	3.94
						820	103.0	97.8	200	198	7,923	3.98
						222	103.0	80.3	220	198	1,996	3.99
						322	103.0	88.0	220	198	3,021	4.16
						422	103.0	91.5	220	198	3,941	4.24
						622	103.0	95.5	220	198	6,043	4.32
						822	103.0	97.3	220	198	7,951	4.36
						425	103.0	90.0	250	198	3,962	4.78
						625	103.0	94.5	250	198	6,059	4.89
